Gear & Transmission - Transmission Oils

GB ATF II

Automatic transmission and power-steering fluid, allows smooth and efficient power transmissions.

OEM Specifications: ALLISON C-4; CATERPILLAR TO-2; GENERAL MOTORS DEXRON® IID; MAN 339-D; MERCEDES

BENZ p236.7; ZF TE-ML-09; ZF TE‑ML‑11; ZF TE-ML-14; VOITH G607; RENK

Technical Datasheet



GB ATF III

A premium automatic transmission and power-steering fluid.  Provides improved low temperature gear shift, increased lubricant and transmission life, and reduced component wear.

OEM Specifications: ALLISON C-4, TES-389; FORD MERCON®; GM DEXRON® III; MAN 339F; MERCEDES BENZ

236.1, 236.5 quality; VOITH 55.6335 (formerly G607); ZF TE-ML 03D, 04D, 14A, 17C

Technical Datasheet



GB ATF TYPE G

A premium automatic transmission fluid for transmission and hydraulic systems, for which the Original Equipment Manufacturer has specified the use of a Ford M2C 33 F/G fluid.

OEM Specifications: FORD M2C 33 F; FORD M2C 33 G

Technical Datasheet



GB TRANSFLUID TO-4 RANGE

Multi-purpose transmission fluids, for off-highway equipment: transmissions, wet disc brakes and final drives.  Meets the latest performance requirements of major OEM’s.

SAE: I0W, 30, 50

OEM Specifications: API CF; API CF-2; ALLISON C-4; DANA POWERSHIFT; CATERPILLAR TO-4 (2005); EATON; KOMATSU DRESSER; KOMATSU (KES 07.868.1 POWERSHIFT TRANSMISSIONS); TEMEC/TTC; ZF TE-ML 03, 03C; ZF TE-ML 01; ZF TE-ML 07F

Technical Datasheet



GB ATF SYNTH 295

A fully synthetic automatic transmission fluid, for use in heavy-duty transmission systems.  Specifically engineered for Allison transmissions requiring a TES-295 product for severe duty and extended drain, it may also be used in transmissions manufactured by Voith, ZF, Borg Warner, Aisin Warner and Bosch, and in other Allison automatic transmissions, when the performance and viscosity grade are applicable.

OEM Specifications: ALLISON TES-295; ALLISON C-4; CATERPILLAR T0-2; DEXRON IIIH/IIE/II; MERCON –V; VOITH G1363; ZF TE-ML-14 B

Technical Datasheet



GB UNITRANS®

For transmissions, wet brakes, power take-off and hydraulics in off-highway applications and agricultural, construction and industrial equipment.

SAE: 15W-30

OEM Specifications: FORD M2C86-B/C; FORD M2C 134D; NH FNHA 2-C-201.00; WHITE FARM (AGCO) Q-186; MASSEY MF 1135/1141/1143/1145; JOHN DEERE J14A; JOHN DEERE J20C/D; CASE MS 1204/5/6/7/8/9/10; FIAT; API GL-4 CRCL20; ALLISON C-4; CATERPILLAR TO-2 ; SAME; LANDINI; DEUTZ; FENDT; RENAULT; KUBOTA; VCE; VOLVO WB101; ZF TE-ML 03E/05E/05F/06D/06K/17E; NH 410B

Technical Datasheet



UNIL MATIC ATF

For semi-automatic, automatic gearboxes and torque convertors for which the OEM has specified the use of a Type A Suffix A fluid.

OEM Formal Approvals: MB-Approval 236.2

OEM Specifications: ALLISON C-4; GENERAL MOTORS TYPE A SUFFIX A
